• Luggage rack, roof-mounted, Black, includes cross rails and integral roller to assist in loading items when in park
• Bumper, front, painted
• Bumper, rear, painted step, includes pad
• Air dam, Dark Gray, unique
• Moldings, lower rocker
• Wheel flares, front and rear (refer to Color Compatibility chart for Matte Black vs. color-keyed wheel flares)
• Assist steps, tubular, mounted between front and rear wheels at bottom of rocker panel
• Grille, color-keyed
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Fog lamps, front, round, halogen
• Mirrors, outside rearview, power folding, power adjustable, heated, color- keyed, driver side electrochromic (light-sensitive auto dimming), turn signal in glass, with ground illumination and curb-tilt
• Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield, driver and front passenger)
• Wipers, intermittent, front, wet-arm with pulse washers
• Door handles, color-keyed
• Body, rear cargo panel doors (Upgradeable to (E52) Body, liftgate with liftglass)

• Seats, front leather seating surfaces reclining buckets, includes adjustable head restraints, inboard armrests, 6-way power adjustable driver seat, floor console and rear storage pockets (Upgradeable to (AN3) Seats, front leather seating surfaces, power reclining full-feature buckets
• Seats, middle leather seating surfaces 60/40 split-folding bench, 3- passenger with center armrest and rear passenger easy entry (Upgradeable to (AL4) Seats, middle leather seating surfaces buckets)
• Seats, rear 3rd row vinyl bench, 3-passenger, 1-piece removable
• Console, floor, includes storage area, map pocket, coin holder, cupholders and integrated 2nd row audio controls
• Floor covering, color-keyed carpeting
• Floormats, color-keyed, carpeted front and 2nd row, removable
• Steering wheel, leather-wrapped rim, Black
• Warning tones, headlamp on, key-in-ignition, driver and right front passenger safety belt unfasten, turn signal on
• Tire pressure monitor (does not apply to spare tire)
• Windows, power, includes driver express-down and lockout features
• Door locks, power programmable, includes lockout protection
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Theft-deterrent system, PASSLock II
• Air conditioning, tri-zone, manual, individual climate settings for driver, right front passenger and rear passengers, includes front and rear HVAC systems (Upgraded to (CJ2) Air conditioning, tri-zone, automatic when (CF5) Sunroof, power or (U42) Entertainment system is ordered)
• Heater and defogger, includes front and side window defoggers, rear passenger heating ducts and heater, rear auxiliary
• Defogger, rear-window, electric
• Sound system, ETR AM/FM stereo with in-dash 6-disc CD changer, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume, TheftLock and Radio Data System (RDS)
• Sound system feature, Bose Premium speaker system, 9 speakers, includes subwoofer in center console
• Sound system feature, rear audio controls, includes dual headphone jacks (headphones not included), power outlet and controls for volume, station selection and media
• OnStar, 1-year Safe and Sound Service, includes automatic notification of air bag deployment, emergency services, roadside assistance, stolen vehicle tracking, AccidentAssist, remote door unlock, remote diagnostics, online concierge and remote horn and lights. Drivers can also opt for other available OnStar services, including making and receiving voice-activated, hands-free phone calls with Personal Calling and getting location-based traffic and weather reports with Virtual Advisor. (Visit onstar.com for system information and details)
• Power outlets, auxiliary, 2 on instrument panel, 1 in cargo area, 12-volt
• Mirror, inside rearview, electrochromic (light-sensitive auto-dimming), 8- point compass, outside temperature indicator and right front passenger air bag status
• Console, overhead mini, includes map lights and rear seat HVAC controls (Includes sunroof controls when (CF5) Sunroof is ordered)
• Headliner, cloth
• Visors, padded, driver and passenger side with cloth trim, extenders, illuminated vanity mirrors and corner storage pockets on back of visors
• Assist handles, front passenger and outboard 2nd row seats
• Lighting, dome lamp, driver and passenger side door switch with delayed entry feature, cargo lamps, door handle or keyless remote activated illuminated entry, map lights in front and 2nd seat positions
• Cargo Package, includes cargo shade, cargo net, cargo mat and luggage rack center rails
• Key, single, 2-sided

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger, includes Passenger Sensing System (front passenger air bag status display on inside rearview mirror) (Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information)
• Safety belts, 3-point, driver and front passenger, in all seating positions except center seating position in 1st and 3rd row which are lap only
• LATCH system, (Lower Anchors and Top tethers for CHildren) for child safety seat
• Daytime running lamps, includes automatic exterior lamp control

ENGINE, VORTEC 5300 V8 SFI FLEX-FUEL

• capable of running on unleaded or up to 85% ethanol (295 HP [219.7 kW] @ 5200 rpm
• 330 lb.-ft. [445.5 N-m] @ 4000 rpm) (STD)

• 3.73 Rear Axle Ratio
• Heavy-Duty Rear Locking Differential
• Driver Convenience Package
• XM Satellite Radio Sound System Feature
• 3-Passenger Removable 3rd Row Rear Bench Seat
• ETR AM/FM Stereo w/6-Disc In-Dash CD Changer
• Liftgate w/Liftglass Rear Door System
• Power Adjustable Pedals
• 60/40 Middle Split-Folding Bench Seat
• Color-Keyed Carpeted Floor Covering
• Removable Color-Keyed Carpeted Floormats
• Rear-Window Wiper/Washer
• Black Roof-Mounted Luggage Rack
• Rear Cargo Panel Doors
• 4-Wheel Disc Brakes
• Front Center Armrest w/Storage
• Compass
• 8 Speakers
• Auto-dimming Rear-View mirror
• Front beverage holders
• Weather band radio
• Variably intermittent wipers
• Tilt steering wheel
• Split folding rear seat
• Speed control
• Security system
• Roof rack: rails only
• Remote keyless entry
• Rear window defroster
• Rear seat center armrest
• Rear reading lights
• Rear anti-roll bar
• Rear air conditioning
• Radio data system
• Power windows
• Power steering
• Power driver seat
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Overhead console
• Outside temperature display
• Occupant sensing airbag
• Low tire pressure warning
• Leather steering wheel
• Illuminated entry
• Heated door mirrors
• Fully automatic headlights
• Front wheel independent suspension
• Front reading lights
• Front fog lights
• Front dual zone A/C
• Front anti-roll bar
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• CD player
• Bumpers: chrome
• Bodyside moldings
• Alloy wheels
• AM/FM radio
• ABS brakes
• 3rd row seats: bench
• Voltmeter
• Tachometer
• Cassette
• Air Conditioning

• Vehicle
• Rear Door Type: Cargo Doors
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 18
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 145
• Cooling System
• Total Cooling System Capacity (qts): 12.6
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2803
• Curb Weight - Rear (lbs): 2576
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 13,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7200
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 720
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: Multi-Link Coil
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 46
• Stabilizer Bar Diameter - Front (in): 1.18
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 12.9 x 1.2
• Tires
• Front Tire Order Code: QJP
• Rear Tire Order Code: QJP
• Spare Tire Order Code: QJP
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/70R17
• Spare Tire Size: P265/70R17
• Front Tire Capacity (lbs): 2134
• Rear Tire Capacity (lbs): 2134
• Spare Tire Capacity (lbs): 2134
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7.0
• Rear Wheel Size (in): 17 x 7.0
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 15.8
• Steering Ratio (:1), At Lock: 15.8
• Turning Diameter - Curb to Curb (ft): 43.7
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: Inboard LH Frame Rail
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/rear bumper (in): 219.3
• Width, Max w/o mirrors (in): 78.9
• Height, Overall (in): 75.4
• Overhang, Front (in): 37.0
• Overhang, Rear w/bumper (in): 52.3
• Ground to Top of Load Floor (in): 31.0
• Ground Clearance, Front (in): 9.8
• Ground Clearance, Rear (in): 8.4
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 104.6
• Cargo Area Length @ Floor to Seat 2 (in): 69.6
• Cargo Area Length @ Floor to Seat 3 (in): 36.1
• Cargo Area Width @ Beltline (in): 49.2
• Cargo Box Width @ Wheelhousings (in): 49.1
• Cargo Box (Area) Height (in): 40.5
• Cargo Volume to Seat 1 (ft³): 131.6
• Cargo Volume to Seat 2 (ft³): 90.0
• Cargo Volume to Seat 3 (ft³): 45.7
• Interior Dimensions
• Passenger Capacity: 8
• Front Head Room (in): 40.7
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 61.3
• Third Head Room (in): 38.6
• Third Leg Room (in): 36.1
• Third Shoulder Room (in): 64.4
• Third Hip Room (in): 49.2
• Summary
• Vehicle Name: Chevrolet Suburban
• Body Style: 4 Door 1500
• Body Code: ZW9
